USAGE

A spectrophotometer is an analytical instrument used to quantitatively measure the transmission or reflection of visible light, UV light or infrared light. Spectrophotometers measure intensity as a function of light source wavelength

CHARACTERISTICS

• The Monochromator with a Holographic flashing Grating is used
• It has the advantage of high wavelength preceision, good monochromatic & low stray light
• A sample Compartmentis equipped with 50 mm cell holder
• Direct concentration read-out and concentration factor setting Function
• Equipped with RS 232 Port.

SPECIFICATION

Display                                         The LCD screen with backlight

Wavelength Rang (nm)         320-1000

Spectral Bandwidth (nm)         2nm

Wavelength Interval                 1 nm

Wavelength Accuracy                 ±2 nm

Wavelength Repeatability         <1 nm

Photometric Accuracy                 ±1%T

Photometric Repeatability         ±0.5%T

Photometric  Range                 0-1.999 A, 0-199.9 %T

Stray Light                                 <0.3%T @ 360 nm

Stability                                            ±0.004A/h @ 500 nm

DIAPLAY                                     4 LCD

Photometric Mode                 T, A, C

DETECHTOR                                 Si Photo diode

LIGHT SOURCE                         TUNGSTEN LAMP

POWER Requirement                 AC 220 V 50 Hz

Cell Glass Cell                             10 ml 4 Nos.

Overall Dimensions (mm)         520 x 450 x 320

Weight (Kg)                                 10 kgs (Gross Weight )
