FEATURES

• Unique optical system 1200 Lies /mm grating and imported receiver to ensure its sound performances.
•  The instrument is supply with PC software expands the capabilities of the instrument includes photometric analysis
• Quantitative analysis , spectral scanning , kinetics, DNA/ protein analysis, Multi-wavelength test etc.
• Adopts 51 microcomputer system and store 200 test data and 100 standard curves.
• Plug type Deuterium Lamp and Tungsten Lamp transfer Lamps without optics debugging
• Automatic Zero and full scale adjustment

SPECIFICATION

Display                                                                     128 x 64 LCd

Detector                                                             Imported Silicon Photodiode

Zero Setting                                                          Automatic

Optical System                                                     Single Beam Grating 1200 Lines/mm

Wavelength Rang (nm)                                 195nm - 1100 nm

Photometric Accuracy                                         +/- 0.5% T

Photometric Repeatability                                  0.2% T

Scope of concentration display                         0-1.999

Wavelength Accuracy (nm)                             1 nm

Wavelength Repeatability(nm)                         <-0.2 nm

Bandwidth (nm)                                                 2nm

Photometric Range                                         0-200 % T -0.3 -3A

Transmittance Accuracy%                                 ±1

Absorbance Repeatability%                         0.3

Stray light %                                                         0.15% T

Stability                                                                 +/- 0.000 A/h @ 500 nm

Baseline Flatness                                                 +/- 0.002 A

Noise%                                                                 +/- 0.001 A

Wavelength Setting                                         Automatic

Light Source                                                         Imported DEUTERIUM & TUNGSTEN LAMP

Output                                                                 USB port & Parallel Port (Printer)

Power                                                                 AC 220 V / 50 Hz

Accessory                                                         USB Cable

                                                                        4 Glass Cell ( 1cm )

                                                                        2 Quartz Cell ( 1cm)

                                                                        Software CD

                                                                        Dust Cover

                                                                        Power Cable

Size                                                             590 x 460 x 220 mm

Weight (Kg)                                                     20 kgs (Gross Weight )
